R contactors for AC circuit switching
1
Rated operational voltage
Ue from 500 up to 1000 V AC
Contactor AC control circuit IORR63..MT IORR125..MT IORR200..MT IORR400..MT IORR500..MT IORR800..MT
type DC control circuit IORE63..MT IORE125..MT IORE200..MT IORE400..MT IORE500..MT IORE800..MT
Categories Ue Ie 85 A 170 A 260 A 400 A 550 A 800 A
AC-1 at 40 °C Ie 85 A 160 A 260 A 400 A 550 A 800 A
AC-3 Ie 56 A 105 A 180 A 280 A 380 A 580 A
690 V AC Power 80 kW 150 kW 240 kW 400 kW 540 kW 780 kW
AC-3 1000 V AC max.
690 V AC
Rated operational voltage
Ue up to 500 V AC
Contactor AC control circuit – IORR800
type – IORE800
DC control circuit
Categories From 85 A to 550 A, select above IOR..-MT 900 A
AC-1 Ue – 800 A
AC-3 – 800 A
at 40 °C Ie – 450 kW
AC-3
380-415-440 V AC Ie
500 V AC max. Ie
400 V AC Power
1/4 | ABB R contactors
