PLC Automation product family

         AC500 and AC500-XC – modular concept




                     1            2               3                              5        4
                                                                                                                    1

















































             Terminal base                                         S500 I/O modules
         1
                                                               4
            – Common for all AC500 CPU types                      – Up to 10 expansions
            – For 1, 2 or 4 communication modules                 – Decentralized extension available.
            – With serial interfaces
            – With 1 or 2 Ethernet interfaces                      Terminal units
                                                               5
            – New specific terminal base only for AC500 V3 CPU with      –  Up to 10 terminal units
           2 Ethernet interfaces and CAN interface.               –  Decentralized extension available.

             Communication modules
         2
            – For PROFIBUS DP , Ethernet, Modbus TCP, EtherCAT
                                                        ®
                           ®
                              ®
                   ®
           CANopen , PROFINET  IO or serial programmable
            – Up to 4 pluggable.
             AC500 central processing unit (CPU)
         3
            – Different performance, memory, network, operating
           conditions options
            – Integrated communication
            – New AC500 V3 CPU with large memory and high
           performance (requires new specific terminal base).
