PLC AUTOMATION PRODUCT FAMILY 19

01

AC500-eCo AC500-eCo V3 AC500 AC500 V3 AC500-S (2) AC500-XC AC500-XC V3 AC500-S-XC (2)
System configuration and application programming
Automation Builder (common programming tool)        
Application Features
Extended temperature range  Pro W version (5)   
Extreme conditions in harsh environments   
Functional safety      
Support of simple motion with FM562 module (1)     
Support of simple motion with onboard I/O PTO/PWM  
Support of PLCopen Motion Control  (3)(5)   (3)(5)    (3)(5) 
not Basic version
Support of High Availability (HA) CS31 based  
Support of High Availability (HA) Modbus TCP based  (4)  (4)  (4)  (4)
Hot Swap of attached I/Os mounted on Hot Swap terminal unit  (9)   (9) 
CPU features AC500-eCo AC500-eCo V3 AC500 AC500 V3 AC500-S (2) AC500-XC AC500-XC V3 AC500-S-XC (2)
Performance (time per binary instruction) 0.08 μs 0.20…0.02 µs 0.0006…0.06 μs 0.001...0.02 µs 0.05 μs 0.0006…0.06 μs 0.001…0.02 μs 0.05 μs
Program memory 128...512 kB 1 ... 8 MB (8) thereof 128 kB…16 MB 8 ... 160 MB (8) thereof 1...1.3 MB 128 kB…16 MB 8 ... 160 MB (8) thereof 1...1.3 MB
User data memory 14...130 kB Prog. code + Data (12) 128 kB…16 MB Prog. code + Data (12) 1024 kB 128 kB…16 MB Prog. code + Data (12) 1024 kB
256 kB... 1 MB 2 MB ... 32 MB 2 MB ... 32 MB
Remanent data (= saved) 2 kB 8… 100 kB 12 kB…3 MB 256 kB ... 1.5 MB 120 kB 12 kB…3 MB 256 kB…1.5 MB 120 kB
Serial communication
RS232  with option board      
RS485   with option board      
Isolated interface Option TA569-RS-ISO  with option board      
Modbus RTU Master/Slave   with option board      
CS31 protocol     
CAN communication interface on CPU
CANopen Master, J1939 and CAN 2A/2B protocols  
Ethernet features on CPU with integrated Ethernet or
external communication module
Online access (Programming)  only onboard  only onboard   only onboard    only onboard 
ICMP (Ping), DHCP, IP configuration protocol  only onboard  only onboard   only onboard    only onboard 
UDP data exchange, Modbus TCP  only onboard  only onboard   only onboard    only onboard 
Ethernet features on CPU with integrated Ethernet only
HTTP / HTTPS (integrated web server)  / -  /  not Basic version  / -  /   / -  / -  /   / -
HTML 5 Web Visu  /  not Basic version  
SNTP (Time synchronization) Client / Server  /   /   /   /   /   /   /   / 
FTP / FTPS server  / -  /   / -  /   / -  / -  /   / -
FTP client  (7)  (7)  (7)  (7)  (7)
SMTP client (Simple Mail Transfer Protocol)   (5)   (5)   (5) for V3  (5) for V3 
IEC 60870-5-104 remote control protocol  Pro version      
MQTT for IoT connection with TLS security  PM556/566 only  not Basic version      
Network variables on UDP     fully
Socket programming         partly
OPC DA (AC500 V2 and V3)         (1) Requires Library PS552-MC-E
OPC UA server (AC500 V3 only)  not Basic version   (2) AC500-S and AC500-S-XC require AC500 or AC500-XC
Selectable protocol modules to operate. The latter supports all communi-
BACnet (B-ASC profile)  (4)  (4)  (4)  (4)  (4)  (4) cation interfaces.
BACnet (B-BC profile)  (4) Pro version  (4)  (4) (3) Requires new V3 Library PS5611-MC
(4) Licensed features, runtime license per CPU.
KNX protocol for building communication  (4) Pro version  (4)  (4) (5) In preparation
IEC 61850 protocol (MMS Server, GOOSE)  (4) Pro version  (4) (6) PM595 and/or CPU V3 only
EtherCAT Master  (4) (5) (11)  (6)  (6) (7) Application library download from
PROFINET IO Controller  (6)  (6) “application examples”
Ethernet/IP Scanner / Adapter  (4) (5)  (4)(5)  (4)(5) (8) Memory size is complete size for program, data and
web server with AC500 V3 CPU, thereof size of
not Basic version User data and User program is smaller
Capability to connect fieldbus modules  CS31, Modbus TCP  Modbus TCP       (9) As of PM585-ETH
I/Os integrated on CPU   with motion I/Os (10) Mounted on Hot Swap terminal unit when attached to
I/O modules features S500-eCo S500 S500 S500-S (2) S500-XC S500-XC S500-S-XC (2) AC500 CPU V2 as of PM585-ETH or AC500 CPU V3 or
Analog modules communication interface modules for Modbus TCP,
Configurable     PROFINET (CI501-PNIO, CI502-PNIO) or PROFIBUS.
Dedicated     (11) Only Standard PM5052 or Pro PM5072 versions
(12) Memory size of V2 versus V3 CPUs is not comparable.
Digital modules Projects have a different and separate User Program
Configurable       code and Data memory calculation in Automation
Dedicated         Builder 2.4.0 version or later: System, configuration and
Transistor outputs short circuit protected       web server parts are not counted anymore. This results
Output diagnosis       in typically about 50% lower memory usage compared
Hot Swap of I/O modules (10)     to V2, and even lower memory usage compared to V3
projects compiled in Automation Builder 2.3.0 or
Extension with S500-eCo and S500(-XC) I/O modules      (2)    (2) before.
