2 | ABB L'essentiel du tableautier – Distribution électrique basse tension

Caractéristiques Article Réf. internationale @ Désignation Col.
Disjoncteurs phase/neutre
Disjoncteurs phase/neutre - Courbe C

SN201L - Icu=6 kA
Nbre pôles In
Ph+N 2 A 470229 2CSS245102R0024 DISJ. Ph/N SN201L-C2 / 4.5 kA 6
Ph+N 6 A 470233 2CSS245102R0064 DISJ. Ph/N SN201L-C6 / 4.5 kA 6
Ph+N 10 A 470236 2CSS245102R0104 DISJ. Ph/N SN201L-C10 / 4.5 kA 6
01
Ph+N 16 A 470238 2CSS245102R0164 DISJ. Ph/N SN201L-C16 / 4.5 kA 6
Ph+N 20 A 470239 2CSS245102R0204 DISJ. Ph/N SN201L-C20 / 4.5 kA 6
Ph+N 25 A 470240 2CSS245102R0254 DISJ. Ph/N SN201L-C25 / 4.5 kA 6
Ph+N 32 A 470241 2CSS245102R0324 DISJ. Ph/N SN201L-C32 / 4.5 kA 6
SN201 - Icu=10 kA
Ph+N 2 A 470629 2CSS255102R0024 DISJ. Ph/N SN201-C2 / 6 kA 6
Ph+N 6 A 470633 2CSS255102R0064 DISJ. Ph/N SN201-C6 / 6 kA 6
Ph+N 10 A 470636 2CSS255102R0104 DISJ. Ph/N SN201-C10 / 6 kA 6
Ph+N 16 A 470638 2CSS255102R0164 DISJ. Ph/N SN201-C16 / 6 kA 6
Ph+N 25 A 470640 2CSS255102R0254 DISJ. Ph/N SN201-C25 / 6 kA 6
Ph+N 20 A 470639 2CSS255102R0204 DISJ. Ph/N SN201-C20 / 6 kA 6
Ph+N 32 A 470641 2CSS255102R0324 DISJ. Ph/N SN201-C32 / 6 kA 6
Disjoncteurs phase/neutre - Courbe D

SN201 - Icu=10 kA
Ph+N 10 A 470661 2CSS255102R0101 DISJ. Ph/N SN201-D10 / 6 kA 6
Ph+N 16 A 470663 2CSS255102R0161 DISJ. Ph/N SN201-D16 / 6 kA 6
Ph+N 20 A 470664 2CSS255102R0201 DISJ. Ph/N SN201-D20 / 6 kA 6
Ph+N 25 A 470665 2CSS255102R0251 DISJ. Ph/N SN201-D25 / 6 kA 6
Ph+N 32 A 470666 2CSS255102R0321 DISJ. Ph/N SN201-D32 / 6 kA 6
Ph+N 40 A 470667 2CSS255102R0401 DISJ. Ph/N SN201-D40 / 6 kA 6
Disjoncteurs différentiels phase/neutre - Courbe C
DS201L - Icu=6 kA
Type AC - 30 mA
Ph+N 6 A 471011 2CSR245041R1064 DISJ.DIF. DS201 L C6 AC30 1
Ph+N 10 A 471012 2CSR245041R1104 DISJ.DIF. DS201 L C10 AC30 1
Ph+N 16 A 471013 2CSR245041R1164 DISJ.DIF. DS201 L C16 AC30 1
Ph+N 20 A 471014 2CSR245041R1204 DISJ.DIF. DS201 L C20 AC30 1
Ph+N 25 A 471015 2CSR245041R1254 DISJ.DIF. DS201 L C25 AC30 1
Ph+N 32 A 471016 2CSR245041R1324 DISJ.DIF. DS201 L C32 AC30 1
Ph+N 40 A 471017 2CSR245041R1404 DISJ.DIF. DS201 L C40 AC30 1
Type A-APR - 30 mA
Ph+N 16 A 471033 2CSR245441R1164 DISJ.DIF. DS201 L C16 APR30 1
Ph+N 20 A 471034 2CSR245441R1204 DISJ.DIF. DS201 L C20 APR30 1
Type AC - 300 mA
Ph+N 6 A 471021 2CSR245041R3064 DISJ.DIF. DS201 L C6 AC300 1
Ph+N 10 A 471022 2CSR245041R3104 DISJ.DIF. DS201 L C10 AC300 1
Ph+N 16 A 471023 2CSR245041R3164 DISJ.DIF. DS201 L C16 AC300 1
Ph+N 20 A 471024 2CSR245041R3204 DISJ.DIF. DS201 L C20 AC300 1
Ph+N 25 A 471025 2CSR245041R3254 DISJ.DIF. DS201 L C25 AC300 1
Ph+N 32 A 471026 2CSR245041R3324 DISJ.DIF. DS201 L C32 AC300 1
Ph+N 40 A 471027 2CSR245041R3404 DISJ.DIF. DS201 L C40 AC300 1
DS201 - Icu=10 kA
Type AC - 30 mA
Ph+N 6 A 471111 2CSR255041R1064 DISJ.DIF. DS201 C6 AC30 1
Ph+N 10 A 471112 2CSR255041R1104 DISJ.DIF. DS201 C10 AC30 1
Ph+N 16 A 471113 2CSR255041R1164 DISJ.DIF. DS201 C16 AC30 1
Ph+N 20 A 471114 2CSR255041R1204 DISJ.DIF. DS201 C20 AC30 1
Ph+N 25 A 471115 2CSR255041R1254 DISJ.DIF. DS201 C25 AC30 1
Ph+N 32 A 471116 2CSR255041R1324 DISJ.DIF. DS201 C32 AC30 1
Ph+N 40 A 471117 2CSR255041R1404 DISJ.DIF. DS201 C40 AC30 1
Type A-APR - 30 mA
Ph+N 16 A 471173 2CSR255441R1164 DISJ.DIF. DS201 C16 APR30 1
Ph+N 20 A 471174 2CSR255441R1204 DISJ.DIF. DS201 C20 APR30 1
Type AC - 300 mA
Ph+N 6 A 471121 2CSR255041R3064 DISJ.DIF. DS201 C6 AC300 1
Ph+N 10 A 471122 2CSR255041R3104 DISJ.DIF. DS201 C10 AC300 1
Ph+N 16 A 471123 2CSR255041R3164 DISJ.DIF. DS201 C16 AC300 1
Ph+N 20 A 471124 2CSR255041R3204 DISJ.DIF. DS201 C20 AC300 1
Ph+N 25 A 471125 2CSR255041R3254 DISJ.DIF. DS201 C25 AC300 1
Ph+N 32 A 471126 2CSR255041R3324 DISJ.DIF. DS201 C32 AC300 1
Ph+N 40 A 471127 2CSR255041R3404 DISJ.DIF. DS201 C40 AC300 1
