AF116B..RT ... AF370B..RT 4-pole contactors

Main accessories

Ordering details (1)
For contactors Auxiliary Type Order code Pkg Weight
contacts qty (1 pce)

1SFC101071V0001 Side-mounted instantaneous auxiliary contact blocks kg

0.04
2nd block
CAL19B-11B-RT
1SFN010829R3311
CAL19B-11-RT AF116B..RT ... AF370B..RT 1st block 1 1 1 1 CAL19B-11-RT 1SFN010829R1011 2 2 0.04 3
Mechanical interlock unit
AF116B..RT ... AF370B..RT VM19 1SFN030300R1000 1 0.054
AF116B..RT ... AF146B..RT and AF190B..RT, AF205B..RT VM140/190 1SFN034403R1000 1 0.088
AF190B..RT, AF205B..RT and AF265B..RT ... AF370B..RT VM205/265 1SFN035203R1000 1 0.09
Note: To mount VM mechanical interlock unit, remove CAL19B-11-RT.
Terminal shrouds LT140-40L 1SFN124203R2000 2 0.09
1SFC101035V0001 AF190B..RT … AF205B..RT, with cable clamps LT205-40C 1SFN124801R2000 2 2 0.06
AF116B..RT … AF140B..RT, with compression lugs
LT205-40L
AF190B..RT … AF205B..RT, with compression lugs
0.29
1SFN124803R2000
1SFN125403R2000
LT370-40L
0.37
AF265B..RT … AF370B..RT, with compression lugs
VM19 AF265B..RT … AF370B..RT, with cable clamps LT370-40C 1SFN125401R2000 2 2 0.04
For contactors Dimensions Type Order code Pkg Weight
qty (1 pce)
hole Ø bar
mm mm kg
Terminal enlargements
AF190B..RT … AF205B..RT 10.5 20 x 5 LW205-40 1SFN074807R2000 1 0.306
AF265B..RT … AF370B..RT 10.5 25 x 5 LW370-40 1SFN075407R2000 1 0.54
(1) For more information, refer to "Accessories" section.

1SFC101264C0201
