Contactors for DC switching applications

         DC-1, DC-3, DC-5 applications according to IEC 60947-4-1





         The circuit switching on DC is more difficult than on AC, as  Operational voltage
         alternating current go to zero according to the frequency of the  – The higher the operational voltage value is, the more difficult

         supply source while DC current has a continuous value.   it is to break the arc.
         The main parameters to be considered for selecting a contac-    – The use of main poles connected in series will allow to in-
         tor are the current, the voltage and the L/R time constant of the   crease the value of switched voltage.
         controlled load.                                        However, the maximum switched voltage must be within the
                                                                 max operational voltage of the contactor.          3
         Time constant and utilization categories                All the poles required for breaking must be connected in
         In DC applications, the nature of load to switch (resistor, induc-  series between the load and the source polarity not linked to
         tance or a combination) is characterized by the ratio of the in-  earth (or chassis) (see recommended connection diagrams).
         ductance to the resistance (L (inductance of operated circuit) / R
         (resistance of operated circuit) = mH/Ω = ms)         ABB offer a large choice of possibilities for DC switching
         This ratio L/R is called the time constant of the circuit.  applications (see selection tables):
                                                                  – AF..(Z)B 3-pole or 4-pole contactors with either 1- pole
         DC current utilization categories are defined according to   breaking or breaking with poles connected in series.
         IEC 60947-4-1:                                           – GAF75..RT designed for DC breaking with permanent
            – DC-1 non inductive or slightly inductive loads, resistance   magnets fitted on the main poles for use with the 3 poles
           furnaces (L/R ≤ 1 ms)                                 connected in series and considered as 1-pole devices.
            – DC-3 shunt motors: starting, plugging, inching, dynamic     – The 3 poles are connected in series via two supplied and
           breaking of DC motors (L/R ≤ 2 ms)                    fitted insulated connections (25 mm²).
            – DC-5 series motors: starting, plugging, inching, dynamic
           breaking of DC motors (L/R ≤ 7.5 ms).               Selection tables
                                                               The enclosed selection tables will guide your choice through
         The higher the time constant value is, the more difficult it is to  all contactor variants according to utilization category, for op-
         break the arc.                                        erational voltage up to 1000 V DC-1 and operational current up
         The addition of a resistor in parallel with an inductive winding helps  to 520 A in ambient temperatures from -25 °C up to 40 °C.
         in the elimination of the arcs, by reducing the time constant.



         Connection diagrams
         Recommended connection
         In the example below, the 3 poles are connected in series without the load in between.
         This connection is recommended in systems according to the following configurations.


          +        -







                                     Indirect earthed system         Direct earthed system       Centre earthed system
                                     (isolated system)
                 Load

         Points to consider                                   Polarity:
         The above relates to power circuit switching. The SCPD (Short  For all GAF75..RT types, connection polarities must be re-
         Circuit Protection Device) must comply with applicable protec-  spected.
         tion rules.                                          (See instruction leaflet and see markings on the main terminals
                                                              or the contactor front)
                                                                                                                    1SBC100193S0201






                                                                                                          ABB  |  3/87
