Coordination with short-circuit protection devices

A complete data base of coordination tables, according to IEC 60947-4-1 (EN 60947-4-1) or UL 508 / UL 60947-4-1, is available on
the ABB Website: see below.
Selection
Simple or multiple selections all from the same screen.

Quick IEC or UL Motor efficiency class Short-circuit protection devices
Start Guide selection and design type • Air circuit breakers
• Fuses "gG" or "aM"
• Moulded case circuit breakers
• Manual motor starters

Overload relay
• Embedded: manual motor starter
/ soft starter
• TOL : thermal overload relay
• EOL : electronic overload relay
• UMC : universal motor controller

Languages Coordination type acc.
to IEC or UL selection
• IEC type 1 or type 2
• UL CMC type A to type F and UL
component rating

Starter type
• Direct-on-line normal start
• Direct-on-line heavy duty
• Star-delta normal start
• Star-delta heavy duty
• Soft starter normal start

Results
• Search results displayed at the bottom of the selection page
• Only the most appropriate solutions to your application, will be displayed at the bottom of the page.
"Enable Smart Current Search" function featured for the short-circuit current where "near to" selected values also are included
in the result.
• Indication of the status (Active, Legacy) of the selected tables
• Possible to print the page to a pdf file or from your printer
• "Clear selection" function to deselect all selected.

13

Access
To find the coordination tables for motor protection, please see: 1SBC101591S0201 - Rev. B
http://applications.it.abb.com/SOC/Page/Selection.aspx
