P. 85
AM-CC-JORE800 and
AMF-CC-JORE800 alternator field discharge contactors
Technical data
Magnet system characteristics
Types Single tripping coil AM-CC-JORE800-21 AM-CC-JORE800-31
AMF-CC-JORE800-21 AMF-CC-JORE800-31
Double tripping coil
At θ ≤ 55 °C 0.85…1.1 x Uc 650 W
Coil operating limits 265 W
24…220 V DC
acc. to IEC 60947-4-1 650 W
265 W
DC control voltage
100 ms
Rated control circuit voltage Uc 55 ms
Coil consumption Average pull-in value
Tripping
Operating time (average values for Uc)
Closing time
Opening time
Mounting characteristics Single tripping coil AM-CC-JORE800-21 AM-CC-JORE800-31 5
Double tripping coil AMF-CC-JORE800-21 AMF-CC-JORE800-31
Types
4 x M12 4 x M12
Fixing by screws (not supplied)
Connecting characteristics
Types Single tripping coil AM-CC-JORE800-21 AM-CC-JORE800-31
AMF-CC-JORE800-21 AMF-CC-JORE800-31
Double tripping coil
48 mm
Connection capacity (min. ... max.) -
2 x ø13 mm
Main conductors (poles)
Terminal plates width 1…2.5 mm²
1…2.5 mm²
Terminal screw (not supplied)
1.5 Nm
Drilling holes (without thread) 1.5 Nm
Auxiliary conductors Screws and bolts
M4 with cable clamps
(built-in auxiliary terminals + coil terminals) M4 with cable clamps
Rigid solid 1 or 2 x
Flexible with non insulated ferrule 1 or 2 x
Tightening torque
Coil terminals
Built-in auxiliary terminals
Screw terminals
Main terminals
Coil terminals
Built-in auxiliary terminals
1SBC104103S0201
ABB R contactors | 5/33
