Spare parts contactors
Active products

Spare part bottom 1

Ordering details Type Order code Pkg Weight
qty (1 pce)
For contactor type 1SFN165503R9231
1SFN165503R9233 kg
A145 Incl. terminal bars 1SFN165503R9235 1.310
A185 Incl. terminal bars 1SFN165503R9237 1.310
A210 Incl. terminal bars 1SFN165503R9239
A260 Incl. terminal bars 1SFN165503R9232 1.960
A300 Incl. terminal bars 1SFN165503R9234 1.960
AF145 Incl. terminal bars 1SFN165503R9236 1.960
AF185 Incl. terminal bars 1SFN165503R9238 1.310
AF210 Incl. terminal bars 1SFN165503R9240 1.310
AF260 Incl. terminal bars 1SFN165503R9241 1.960
AF300 Incl. terminal bars 1SFN165503R9241 1.960
AF400 Incl. terminal bars 1SFN165503R9243 1.960
AF460 Incl. terminal bars 1SFN165503R9243 4.635
AF580 Incl. terminal bars 1SFN165503R9245 4.635
AF750 Incl. terminal bars 1SFN165503R9246 5.135
AF1250 Incl. terminal bars and fixed contacts 1SFN165503R9250 5.135
AF1350 Incl. terminal bars and fixed contacts 1SFN165503R9246 6.215
AF1350 (1) 1SFN165503R9251 18.060
AF1650 Incl. terminal bars and fixed contacts 1SFN165503R9248 15.700
AF1650 (1) 1SFN165503R9252 18.060
AF2050 Incl. terminal bars and fixed contacts 1SFN165503R9249 15.700
AF2050 (1) 18.305
AF2650 (2) Base part (plastic) 15.700
9.300

(1) From contactor serial number 1S160100514030001
(2) No terminal bars or fixed contacts included.

AFKIT Service kit
AFBRG
Description
This kit contains various parts as rubber bearings, springs, levers, plastic armatures, cable holders,
screws.

Ordering details

For contactor type Type Order code Pkg Weight
AFKIT 1SFN165503R9253 qty (1 pce)
AF1350 .... AF2050 (1)
(1) Until serial no. 1S16100514029999 kg

1 0.200

Contactor bridge Type Order code Pkg Weight
1SFN165503R9254 qty (1 pce)
Description
Includes 3 contactor bridges and 6 springs. kg
1 1.000
Ordering details

For contactor type

AF1350 .... AF2050 AFBRG

ABB Spare parts | 1/7
