Spare parts contactors
Classic products

1 Adapter plates

PR300-1 Description

L Adapter plates with fixing holes for specified old contactors to new contactors.
h
1SFT98001-015C3 Ordering details To new contactor Type Order code Pkg Weight
qty (1 pce)
From old contactor

EH65, EH75, EH80, EH90, EG80 A95, A110 PR110-1 1SFN094500R1000 kg
1 0.270
EH100, EH145 A110, A145 PR145-1 1SFN094700R1000 1 0.360
1 0.440
EH150, EH160, EH175, EH210, A185, A210 PR210-1 1SFN094900R1000
EG160 A210...A300 PR300-1 1SFN095300R1000 1 0.560
EH250, EH260, EH300 1 0.900
1 0.500
EH370, EH550, EG315 AF400...AF580 PR460-1 1SFN095700R1000 1 1.100

EH700, EH800 AF750 PR750-1 1SFN096100R1000

EH550, EG630 AF580, AF750 PR750-2 1SFN096100R1001

Note: The adapter plates provided for the A ... contactors can also be used for the AF ... contactors.

l

E2119D Dimensions (mm) Dimensions Ih Fixing holes
106 11.2
Type of the plate L 122 11.5 mm
151 132 11.5 2xø7
PR110-1 180 172 11.5 4xø7
PR145-1 200 198 11.5 4xø7
PR210-1 200 244 11.5 4xø7
PR300-1 278 4xø7
PR460-1 283 4xø7
PR750-1

Note: The adapter plates provided for the A ... contactors can also be used for the AF ... contactors.
Fixing holes according to the plate types

1/14 | ABB Spare parts
