Modular range
Non-illuminated selector switches - 3-position - Short handle

02
Operating Color Bezel Type Order code Pkg Weight
principle qty (1 pce)
1SFC151317V0001 l Red Black plastic M3SS1-10R 1SFA611210R1001 10 0.015
kg
Chrome plastic
M3SS1-20R
10
0.015
1SFA611210R2001
Chrome metal M3SS1-30R 1SFA611210R3001 10 0.024
M3SS1-30R
l Black Black plastic M3SS1-10B 1SFA611210R1006 10 0.015
Chrome plastic M3SS1-20B 1SFA611210R2006 10 0.015
1SFC151130V0001 l Grey Chrome metal M3SS1-30B 1SFA611210R3006 10 0.024
0.015
Black plastic
1SFA611210R1007
M3SS1-10U
10
Chrome plastic
10
M3SS1-20U
0.015
1SFA611210R2007
Chrome metal M3SS1-30U 1SFA611210R3007 10 0.024
M3SS2-10B
l Red Black plastic M3SS2-10R 1SFA611211R1001 10 0.015
Chrome plastic M3SS2-20R 1SFA611211R2001 10 0.015
Chrome metal M3SS2-30R 1SFA611211R3001 10 0.024
1SFC151129V0001 l Black Black plastic M3SS2-10B 1SFA611211R1006 10 0.015
10
0.015
Chrome plastic
1SFA611211R2006
M3SS2-20B
1SFA611211R1007
M3SS2-10U
0.015
10
Black plastic
M3SS3-10U l Grey Chrome metal M3SS2-30B 1SFA611211R3006 10 0.024
Chrome plastic M3SS2-20U 1SFA611211R2007 10 0.015
l Red Black plastic M3SS3-10R 1SFA611212R1001 10 0.015
l Black Black plastic M3SS3-10B 1SFA611212R1006 10 0.015
Chrome plastic M3SS3-20B 1SFA611212R2006 10 0.015
Chrome metal M3SS3-30B 1SFA611212R3006 10 0.024
l Grey Black plastic M3SS3-10U 1SFA611212R1007 10 0.015
Chrome plastic M3SS3-20U 1SFA611212R2007 10 0.015
l Red Black plastic M3SS7-10R 1SFA611216R1001 10 0.015
Chrome plastic M3SS7-20R 1SFA611216R2001 10 0.015
l Black Black plastic M3SS7-10B 1SFA611216R1006 10 0.015
Contacts actuated Chrome plastic M3SS7-20B 1SFA611216R2006 10 0.015
Chrome metal M3SS7-30B 1SFA611216R3006 10 0.024
Right
l Grey Black plastic M3SS7-10U 1SFA611216R1007 10 0.015
Left
Left block Right block
Handle position
Not actuated Actuated

1.5 0.06" - 6 0.24"

26.5 1.04"
43 1.69" Ø 29 1.14"

30 1.18" 48.5 1.91" 30 1.18"
M3SS 1SFC151015S0201
Dimensions (mm, inches)
