PAM100015, PCT, KA marker holders
For component and equipment markers

Description
–– Self-adhesive marking profile (PAM), transparent cover (PCT) and push-button marker holder (KA1),
–– To be used with PAM21515, PAM43015, PSP and PPB labels.

1SNC160268F0014 Main technical data Flammability Temperature range
V0 (for PAM and PCT) -10°C to +70°C +14°F to +158°F (for PAM and PCT)
Material V2 (for KA1) -25°C to +70°C -13°F to +158°F (for KA1)
PVC (for PAM and PCT)
Polycarbonate (for KA1)

Ordering details Color Type Order code Pkg Weight 4
pce (1 pce) g
Dimensions

mm in

Push-button marker holder

K A1

Push button marker holder for PPB markers.

15 x 27 0.591 x 1.063 Black KA1-8120 1SFA616920R8120 10 2.00

KA1-8120 Self-adhesive marking profile for PAM, PSP and PPB markers.

PCT100015 PCT

PAM100015 Transparent cover for PAM100015

15 x 1000 0.591 x 39.370 Transparent PCT100015 1SNA235147R2600 35 34.00
35 40.00
PAM100015

Self-adhesive marking profile for PAM, PSP and PPB markers.

15 x 1000 0.591 x 39.370 Black PAM100015 1SNA235146R2500

Dimensions given apply to the labelling area.

1SNC160131S0201

All the technical data for UL/CSA standard and dimensions in inches are in italic.
