HTP500 markers selection guide
for other manufacturers' terminal blocks
Terminal block Depending on type, markers are presented as
joined strips at a set or as separate markers
Terminal block markers are available in ver- for convenient individual insertion on mixed
sions to suit the particular terminal block spacing terminal block assemblies.
formats of the most widely used products, see
selection guide to side.
Markers Individual markers
Strip markers Marker spacing
Marker width
6
Marker spacing
Marker width
S - Strip mounting Marker spacing = Terminal block spacing
I - Individual mounting Marker spacing ≠ Terminal block spacing
T - Top mounting
