Primary switch mode power supplies
Overview

Modern power supply units are a vital component in most areas of energy management and automation technology. ABB as
your global partner in these areas pays the utmost attention to the resulting requirements. Innovation is the key to a substantial
enlargement of our power supply product program:

CP-D CP-S

The CP-D range of power supply units in MDRC design The CP-S range is ABB’s standard range, a high-end power

(modular DIN rail components) fits into all domestic installation supply unit optimised for serial applications.

3 and distribution panels.

CP-E CP-C
The CP-E range offers enhanced functionality while the num- The CP-C range’s pluggable function modules adapt these
ber of different types has been considerably reduced. Now all power supply units exactly to your application’s needs. Of
power supply units can be operated at an ambient tempera- course, all ABB power supply units feature primary switch
ture of up to +70 °C. mode technology – environmentally sound and cost-efficiency.
This represents the highest level of innovative industrial elec-

tronics.

CP-T

The CP-T range of three-phase power supply units is ABB’s

youngest member of the power supply family.

Application manual The manual is available in English and German.
For today’s applications, e.g. in control engineering, it is es- English Version: 2CDC 114 048 M0203
sential to make the right decision regarding the selection and German Version: 2CDC 114 048 M0103
planning of the power supply unit. Incorrect dimensioning or
incorrect connection of a power supply unit can seriously af-
fect the safety and/or availability of the entire installation.
ABB’s “Power Supply Units” application manual provides a
general overview of switch mode power supply units, thus
helping you to choose the ideal power supply unit and avoid
problems during engineering and commissioning. The manual
generally shows and explains the fundamental characteristics
of and the differences between power supply units, and pro-
vides a detailed introduction to the ABB product range on the
basis of the selection criteria. Finally, it describes and explains
application examples for engineering.
