5/212 ABB PRODUITS ET SOLUTIONS MOYENNE ET BASSE TENSION

—
System pro E power
Kits internes

Plastrons pleins
Plastrons avec vis à 1/4 tour, à charnières à droite ou à gauche avec le kit approprié PHFP0020.

1/4 Dimensions
(mm)
Emballage/
Description H L Réf. internationale @ Article N° pièces
Plastron plein 50 400 1STQ007465A0000 PPFB5040 1/1
Plastron plein 100 400 1STQ007466A0000 PPFB1040 1/1
Plastron plein 150 400 1STQ007467A0000 PPFB1540 1/1
Plastron plein 200 400 1STQ007468A0000 PPFB2040 1/1
Plastron plein 250 400 1STQ007469A0000 PPFB2540 1/1
Plastron plein 300 400 1STQ007470A0000 PPFB3040 1/1
Plastron plein 350 400 1STQ002015B0000 PPFB3540 1/1
Plastron plein 400 400 1STQ007471A0000 PPFB4040 1/1
Plastron plein 450 400 1STQ002016B0000 PPFB4540 1/1
Plastron plein 500 400 1STQ007472A0000 PPFB5004 1/1
Plastron plein 600 400 1STQ007473A0000 PPFB6040 1/1
Plastron plein 800 400 1STQ007474A0000 PPFB8040 1/1
Plastron plein 1800 400 1STQ007475A0000 PPFB1840* 1/1
Plastron plein 2000 400 1STQ007476A0000 PPFB2004* 1/1
Plastron plein 50 600 1STQ007477A0000 PPFB5060 1/1
Plastron plein 100 600 1STQ007478A0000 PPFB1060 1/1
Plastron plein 150 600 1STQ007479A0000 PPFB1560 1/1
Plastron plein 200 600 1STQ007480A0000 PPFB2060 1/1
Plastron plein 250 600 1STQ007481A0000 PPFB2560 1/1
Plastron plein 300 600 1STQ007482A0000 PPFB3060 1/1
05
Plastron plein 350 600 1STQ002017B0000 PPFB3560 1/1
Plastron plein 400 600 1STQ007483A0000 PPFB4060 1/1
PFPF.... Plastron plein 450 600 1STQ002018B0000 PPFB4560 1/1
PFPS.... Plastron plein 500 600 1STQ007484A0000 PPFB5006 1/1
Plastron plein 600 600 1STQ007485A0000 PPFB6060 1/1
Plastron plein 800 600 1STQ007486A0000 PPFB8060 1/1
Plastron plein 1800 600 1STQ007487A0000 PPFB1860* 1/1
Plastron plein 2000 600 1STQ007488A0000 PPFB2006* 1/1
Plastron plein 50 800 1STQ007489A0000 PPFB5080 1/1
Plastron plein 100 800 1STQ007490A0000 PPFB1080 1/1
Plastron plein 150 800 1STQ007491A0000 PPFB1580 1/1
Plastron plein 200 800 1STQ007492A0000 PPFB2080 1/1
Plastron plein 250 800 1STQ007493A0000 PPFB2580 1/1
Plastron plein 300 800 1STQ007494A0000 PPFB3080 1/1
Plastron plein 350 800 1STQ002019B0000 PPFB3580 1/1
Plastron plein 400 800 1STQ007495A0000 PPFB4080 1/1
Plastron plein 450 800 1STQ002020B0000 PPFB4580 1/1
Plastron plein 500 800 1STQ007496A0000 PPFB5008 1/1
Plastron plein 600 800 1STQ007497A0000 PPFB6080 1/1
Plastron plein 800 800 1STQ007498A0000 PPFB8080 1/1
Plastron plein 1800 800 1STQ007499A0000 PPFB1880* 1/1
Plastron plein 2000 800 1STQ007500A0000 PPFB2008* 1/1
Plastron plein 100 1000 1STQ007501A0000 PPFB1010 1/1
Plastron plein 150 1000 1STQ001479B0000 PPFB1510 1/1
Plastron plein 200 1000 1STQ007502A0000 PPFB2010 1/1
Plastron plein 300 1000 1STQ007503A0000 PPFB3010 1/1
Plastron plein 400 1000 1STQ007504A0000 PPFB4010 1/1
Plastron plein 500 1000 1STQ007505A0000 PPFB5001 1/1
Plastron plein 600 1000 1STQ007506A0000 PPFB6010 1/1
Plastron plein 800 1000 1STQ007507A0000 PPFB8010 1/1
Plastron plein 200 1250 1STQ007511A0000 PPFB2012 1/1
Plastron plein 300 1250 1STQ007512A0000 PPFB3012 1/1
Pour le montage des plastrons internes commander le support fixe approprié PFPF.... ou pivotant PFPS.....
* Seulement pour support pivotant PFPS…. Pas compatible avec l'accessoire charnière PHFP0020.
