Page 1165 - Entrelec Terminal Blocks Master Catalog

MC812PA terminal block markers
Pre-printed markers for SNK series

8 mm 0.315 in spacing - vertical mounting

Ordering details
Description Color Type Part Number Pkg Weight
card (1 card) g
← Continuation of previous page
K (x100) White MC812PA 1SNK166112R0000 5 14.00
L (x100) White MC812PA 1SNK166122R0000 5 14.00
M (x100) White MC812PA 1SNK166132R0000 5 14.00
N (x100) White MC812PA 1SNK166142R0000 5 14.00
O (x100) White MC812PA 1SNK166152R0000 5 14.00
P (x100) White MC812PA 1SNK166162R0000 5 14.00
Q (x100) White MC812PA 1SNK166172R0000 5 14.00
R (x100) White MC812PA 1SNK166182R0000 5 14.00
S (x100) White MC812PA 1SNK166192R0000 5 14.00
T (x100) White MC812PA 1SNK166202R0000 5 14.00
U (x100) White MC812PA 1SNK166212R0000 5 14.00
V (x100) White MC812PA 1SNK166222R0000 5 14.00
W (x100) White MC812PA 1SNK166232R0000 5 14.00
X (x100) White MC812PA 1SNK166242R0000 5 14.00
Y (x100) White MC812PA 1SNK166252R0000 5 14.00
Z (x100) White MC812PA 1SNK166262R0000 5 14.00

Card with 100 markers, repeated identical symbols
+ + + + + + + + + + + (x100) White MC812PA 1SNK168002R0000 5 14.00
- (x100) White MC812PA 1SNK168012R0000 5 14.00
~ (x100) White MC812PA 1SNK168022R0000 5 14.00
+ + + + + + + + + +
= (x100) White MC812PA 1SNK168032R0000 5 14.00
(x100) White MC812PA 1SNK168042R0000 5 14.00
+ + + + + + + + + + + + + + + + + + + + L1 (x100) White MC812PA 1SNK168052R0000 5 14.00 5
L2 (x100) White MC812PA 1SNK168062R0000 5 14.00
L3 (x100) White MC812PA 1SNK168072R0000 5 14.00
+ + + + + + + + + + + + + + + + + + + +
PE (x100) White MC812PA 1SNK168092R0000 5 14.00
U1 (x100) White MC812PA 1SNK168102R0000 5 14.00
U2 (x100) White MC812PA 1SNK168112R0000 5 14.00
U3 (x100) White MC812PA 1SNK168122R0000 5 14.00
V1 (x100) White MC812PA 1SNK168132R0000 5 14.00
V2 (x100) White MC812PA 1SNK168142R0000 5 14.00
V3 (x100) White MC812PA 1SNK168152R0000 5 14.00
W1 (x100) White MC812PA 1SNK168162R0000 5 14.00
W2 (x100) White MC812PA 1SNK168172R0000 5 14.00
W3 (x100) White MC812PA 1SNK168182R0000 5 14.00
+24V (x100) White MC812PA 1SNK168192R0000 5 14.00
+48V (x100) White MC812PA 1SNK168202R0000 5 14.00
-24V (x100) White MC812PA 1SNK168212R0000 5 14.00
-48V (x100) White MC812PA 1SNK168222R0000 5 14.00

L1 L2 L3 N PE L1 L2 L3 N PE

L1 L2 L3 N PE L1 L2 L3 N PE Card with 100 markers, 5 different symbols repeated 20 times
L1-L2-L3-N-PE (x20) White MC812PA 1SNK169002R0000 5 14.00
L1 L L L2 L L L3 L L N N PE P P P L1 L L L2 L L L3 L L N N PE P P P

1 2 L2 L3 3 N N E E 1 L2 2 L3 3 N N E E
L L L L P P L L L L P P
Card with 100 markers, 9 different symbols repeated 10 times
U1 U2 U3 V1 V2 V3 W1 W2 W3 U1 U1-U2-U3-V1-V2-V3-W1-W2-W3 (x10) + U1 (x10) White MC812PA 1SNK169012R0000 5 14.00

U1 U2 U3 V1 V2 V3 W1 W2 W3 U1
U1 U U U U2 U U U U3 U U U V1 V V V V2 V V V V3 V V V W1 W W W W W2 W W W W W3 W W W W U1 U U U 1SNC160164S0201

1 2 2 3 3 1 2 3 3 1 2 3 1
U U U U U U V V V V V V W1 W W W2 W W W3 W W U U
