Page 79 - Entrelec Terminal Blocks Master Catalog

SNK series, terminal blocks
Screw clamp technology

Technologies presentation 72
Overview 76
Feed-through
4 mm² / 12 AWG ZS4 80
6 mm² / 10 AWG ZS6 81
ZS6-3S and ZS6-4S with 3 and 4 connections 82-83
10 mm² / 6 AWG ZS10 84
16 mm² / 4 AWG ZS16 85
25 mm² / 3 AWG ZS25 86
35 mm² / 0 AWG ZS35 87
50 mm² / 0 AWG ZS50 88
70 mm² / 00 AWG ZS70 89
95 mm² / 0000 AWG ZS95 90
150 mm² / 350 Kcmil ZS150 91
240 mm² / 240 Kcmil ZS240 92
Ground
4 mm² / 12 AWG ZS4-PE 93
6 mm² / 10 AWG ZS6-PE 94
ZS6-3S-PE and ZS6-4S-PE with 3 and 4 connections 95-96
10 mm² / 6 AWG ZS10-PE 97
16 mm² / 4 AWG ZS16-PE 98
25 mm² / 3 AWG ZS25-PE 99
35 mm² / 2 AWG ZS35-PE 100
35 mm² ZS35-PEN + neutral 101
50 mm² / 0 AWG ZS50-PE 102 3
70 mm² / 00 AWG ZS70-PE 103
95 mm² / 0000 AWG ZS95-PE 104
Disconnect with blade
4 mm² / 10 AWG ZS4-S, ZS4-S-T, ZS4-S-R1 and ZS4-S-T-R1 with test 105-108
6 mm² / 10 AWG ZS6-S and ZS6-S-4S-T with test 109-110
10 mm² / 6 AWG ZS10-S 111
Disconnect with plug
4 mm² / 10 AWG ZS4-SP, ZS4-SP-T2, ZS4-SP-R1 and ZS4-SP-T2-R1 with test 112-115
10 mm² / 6 AWG ZS10-SP 116
Fuse and marshalling cabinets application overview 118
For 5x20 and 5x25 mm fuses
4 mm² / 10 AWG ZS4-SF1 and ZS4-SF1-T with test 120-121
ZS4-SF1-R with fuse indicator and test 122-123
ZS4-R1 feed-through 124
ZS4-S-R3 disconnect with lever 125
For 5x20 mm fuses and marshalling cabinets application
4 mm² / 10 AWG ZS4-SF 126
ZS4-SF-T with test 127
ZS4-SF-R with fuse indicator and test 128-129
ZS4-R2 feed-through 130
ZS4-PE-R2 ground 131
ZS4-S-R2 disconnect with lever 132
For 6.3x32 mm fuses (¼ x 1¼ in)
10 mm² / 6 AWG ZS10-SF 133
ZS10-SF-R with fuse indicator 134
ZS10-S-R2 disconnect with lever 135
Double deck
4 mm² / 12 AWG ZS4-D2 and ZS4-D1 2 and 1 feed-through circuits 136-137
6 mm² / 10 AWG ZS6-D2 and ZS6-D1 2 and 1 feed-through circuits 138-139
ZS6-D2-PE 1 feed-through circuit and 1 ground circuit 140
ZS6-D1-PE 1 ground circuit 141
4 mm² / 10 AWG ZS4-D2-S 1 disconnect circuit and 1 feed-through circuit 142
ZS4-D2-S-T 1 disconnect circuit + test and 1 feed-through circuit 143
ZS4-D2-SF1 1 fuse circuit and 1 feed-through circuit 144
ZS4-D2-SF1-R 1 fuse circuit + fuse indicator and 1 feed-through circuit 145
Triple deck
4 mm² / 12 AWG ZS4-T3 3 feed-through circuits 146
4 mm² / 10 AWG ZS4-T3-R1 3 feed-through circuits 147
Component holder
4 mm² / 12 AWG ZS4-D-CH-UD and ZS4-D-CH-DU 148-149
Test and measurement
Overview 150
10 mm² / 6 AWG ZS10-ST 154
ZS10-ST-1 for Potential Transformer circuits 155
ZS10-ST-T4 for Current Transformer circuits 156 Summary_3
ZS10-R1 feed-through 157
ZS10-PE-R1 ground 158

PAGE 71
