Page 11 - Railways Applications Terminal blocks

Railway solutions and tools
Easy Rail Designer 3D, Terminal block assembly software

Engineering, do it yourself easily

1

Advanced 3D drawing and data export Customized project management User-friendly configurator
– Built-in 3D viewer – Management of multiple projects – Intuitive Windows ® (1) user interface
– Integration to CAD/CAE softwares – Indication on the drawing of the – Autocorrecting system
– Compatibility with TE Connectivity supplier's, integrator's and end – Powerful search engine
printers user's data – Insertion of products external to the
– Detailed drawings of the rail, assem- – Drawing update indexing with PDF database.
bly and markers. report.
(1) Windows® is a registered trademark of Microsoft.
Assembling, rely on TE Connectivity expertise

TE Connectivity technical expertise Flexible production Optimized inventory
– Drawing technical verification done – 3 types of assembly: – Products and markers stocked by TE
by TE Connectivity experts - rail mounted Connectivity
– 100% reliable data import to TE Con- - pre-assembled – Marking managed by TE Connectivity
nectivity production system. - packed in kit. – One single product part number
– Possibility to add some other TE corresponds to one complete 1SNC167101S0201
Connectivity Din rail products. assembly.
