Reversing starters protected by electronic overload relays

With AF contactors - open type version in kit form

Main dimensions mm, inches
280 11.02" 180 7.09"

5
477.5 18.80"

12 X
43.75 96.25 3.79" 43.75 M5 10-24 UNC
1.72" 1.72"

187 7.36"

90.5 3.56"

112 4.41"

35
1.38"
AF265, AF305, AF370 1SFC101160C0201
+ BER370-4, VM19
+ EF370 electronic overload relay
