Star-delta starters protected by thermal overload relays

With AF contactors - Open type version in kit form

Main dimensions mm, inches
102.5 4.04"
135 5.31" 71 2.80" 10
0.39" 125 4.92" 4 x
35 1.38" M4 8-32 UNC
35 mm EN/IEC 60715 5.5 0.22" 60 2.36" 70 2.76"

166.5 6.55" 5 0.20"

ø 4.2 0.17" 5 0.20"
6.2
0.24"
5
AF09, AF12, AF16 72.7 2.86"
+ BEY16-4, VEM4 76.8 3.02"
+ TF42 thermal overload relay

119.5 4.70"
135 5.31" 80 3.15" 10
0.39"
2 x
125 4.92" M4 8-32 UNC
35 mm EN/IEC 60715 5.5 0.22" 60 2.36" 70 2.76"

171 6.73" 5 0.20"

ø 4.2 0.17" 5 0.20"

9.2 0.36"
AF26, AF30, AF38 75.7 2.98"
+ BEY38-4, VEM4, CA4-10 79.8 3.14"
+ TF42 thermal overload relay

102.5 4.04"
135 5.31" 71 2.80" 10
0.39" 125 4.92" 4 x
35 1.38" M4 8-32 UNC
35 mm EN/IEC 60715 5.5 0.22" 60 2.36" 70 2.76"

166.5 6.55" 5 0.20"

ø 4.2 0.17" 5 0.20"
6.2
0.24" 1SBC101963S0201
Note: contactor lateral distance to grounded component 2 mm 0.08" min.
