Main accessories

MS165, MO165

Description
2CDC241002V0015 Three-phase busbars ensure a quick and safe connection and are therefore a cost effective solution.
A variety of different three-phase busbars up to 125 A are in the assortment. Between 2 and 5 manual
motor starters with none, one or two lateral auxiliary contacts can be connected.
2 Ordering details
PS2-2-0-125
Suitable for Rated Number of Number of Type Order code Pkg Weight
operational MMS lateral aux. qty (1 pce)
2CDC241003V0015 current kg
A
Three-phase busbars
MS165, 125 2 0 PS2-2-0-125 1SAM401920R1002 10 0.100
PS2-3-0-125 MO165 125 3 0 PS2-3-0-125 1SAM401920R1003 10 0.162
125 4 0 PS2-4-0-125 1SAM401920R1004 10 0.226
125 2 2 PS2-2-2-125 1SAM401920R1022 10 0.117
125 3 2 PS2-3-2-125 1SAM401920R1023 10 0.197
125 4 2 PS2-4-2-125 1SAM401920R1024 10 0.277
2CDC241010V0014 Other busbar types on request.

KA165 Suitable for Description Type Order code Pkg Weight
(1 pce)
qty
2CDC241001V0015 MS165, MO165 Terminal shroud KA165 1SAM401922R1001 10 kg
0.025
1SAM401921R1001
0.005
10
Protection cover for busbars BS2-3
Padlock + two keys SA2 GJF1101903R0002 10 0.020
BS2-3
2CDC241023F0013

SA2

2CDC131050C0201

2/34 | ABB
