Auxiliary contact blocks for AF09 ... AF96 contactors and

NF contactor relays

Description
The auxiliary contact blocks are used for the operation of auxiliary circuits and control circuits for standard
1SBC100001V0014 industrial environments.
Types of auxiliary contact blocks for front mounting:

– CC4
1-pole block, with N.O. leading contact or N.C. lagging contact
CA4-10 – CA4 1 or 4-pole block, with instantaneous N.O., N.C. contacts
– CAT4 2-pole block, with instantaneous N.O. + N.C. contacts and A1 / A2 coil terminal connection on
front face.
Select the 4-pole auxiliary contact blocks CA4-..E, CA4-..M, CA4-..U or CA4-..N type, according to the
contactor or contactor relay type for compliance with the standard requirements (see "Terminal marking and
1SBC100007V0014 positioning").
Types of auxiliary contact blocks for side mounting:
– CAL4 2-pole block, with instantaneous N.O. + N.C. contacts.
For clipping onto the right- and/or left-hand side of the contactors.
5 CAL4-11 The auxiliary contact blocks are equipped with screw type connecting terminals delivered open, protected
against accidental direct contact and bear the corresponding function marking.

1SBC100006V0014 Ordering details (1) Auxiliary contacts Type Order code Pkg Weight
For contactors
qty
(1 pce)
kg
CA4-22E
Front-mounted instantaneous auxiliary contact blocks
AF09 ... AF96 1 0 – – CA4-10 1SBN010110R1010 1 0.014
4-pole NF 1 0 – – CA4-10-T 1SBN010110T1010 10 0.014
0.014
CA4-01
1
1SBN010110R1001
0 1
1SBC100002V0014 AF09 ... AF16..-30-10 0 1 – – CA4-01-T 1SBN010110T1001 10 0.014
– –
1
0.055
– –
2 2
CA4-22M
1SBN010140R1122
3 1
1SBN010140R1113
1 3 – – CA4-31M 1SBN010140R1131 1 1 0.055
0.055
CA4-13M
– –
CAT4-11E 0 4 – – CA4-04M 1SBN010140R1104 1 0.055
AF26 ... AF96..-30-00 2 2 – – CA4-22E 1SBN010140R1022 1 0.055
AF09 ... AF80..-40-00 3 1 – – CA4-31E 1SBN010140R1031 1 0.055
AF09 ... AF80..-22-00 4 0 – – CA4-40E 1SBN010140R1040 1 0.055
AF26 ... AF96..-30-00 0 4 – – CA4-04E 1SBN010140R1004 1 0.055
AF09 ... AF16..-40-00
AF40 ... AF80..-40-00
AF09 ... AF16..-30-01 2 2 – – CA4-22U 1SBN010140R1322 1 0.055
3 1 – – CA4-31U 1SBN010140R1331 1 0.055
4 0 – – CA4-40U 1SBN010140R1340 1 0.055
4-pole NF 2 2 – – CA4-22N 1SBN010140R1222 1 0.055
3 1 – – CA4-31N 1SBN010140R1231 1 0.055
4 0 – – CA4-40N 1SBN010140R1240 1 0.055
1 3 – – CA4-13N 1SBN010140R1213 1 0.055
NF..40E 0 4 – – CA4-04N 1SBN010140R1204 1 0.055
Front-mounted auxiliary contact blocks with N.O. leading contact and N.C. lagging contact
AF09 ... AF96 – – 1 0 CC4-10 1SBN010111R1010 1 0.014
4-pole NF – – 0 1 CC4-01 1SBN010111R1001 1 0.014
Side-mounted instantaneous auxiliary contact blocks
AF09 ... AF96 1 1 – – CAL4-11 1SBN010120R1011 1 0.040
NF 1 1 – – CAL4-11-T 1SBN010120T1011 10 0.040
Front-mounted instantaneous auxiliary contact and A1/A2 coil terminal blocks
AF09 ... AF16..-30-10 1 1 – – CAT4-11M 1SBN010151R1111 1 0.040
AF26 ... AF65..-30-00 1 1 – – CAT4-11E 1SBN010151R1011 1 0.040
AF09 ... AF52..-40-00
AF09 ... AF40..-22-00 1SBC101573S0201 - Rev. A
AF09 ... AF16..-30-01 1 1 – – CAT4-11U 1SBN010151R1311 1 0.040
(1) For each contactor or contactor relay type, refer to "Accessory fitting details" table.
Note: CAT4 not suitable for AF..Z contactors with DC control voltage 12…20 V DC.
5/342 | ABB
