Voltage code table

GAF1650, GAF2050 contactors

Auxiliary contacts
N.O. N.C.
Type Order code
GAF1650 - 10 - 11 1SFL677025R 70 11
AC coil code DC coil code
50/60 Hz
N.O. N.C. 70 100...250 V 100...250 V
Main contacts

Contactor type
GAF AC / DC operated
5

UA..RA contactors

Auxiliary contacts
N.O. N.C. Contactors: UA..RA
Type Order code AC coil code
UA16 - 30 - 10 RA 1SBL181024R 84 10 50 Hz 60 Hz
81 24 V 24 V
84 110 V 110...120 V
89 110...115 V 115...127 V
N.O. N.C. 36 190 V 220 V
Main contacts 80 220...230 V 230...240 V
88 230...240 V 240...260 V
85 380...400 V 400...415 V
Contactor type 86 400...415 V 415...440 V
UA..RA Capacitor switching - AC operated 75 200 V 200...220 V

Codes in bold for dual frequency coils.

UA contactors

Auxiliary contacts
N.O. N.C. Contactors: UA
Type Order code AC coil code
50 Hz 60 Hz
UA16 - 30 - 10 1SBL181022R 83 10 81 24 V 24 V
83 48 V 48 V
84 110 V 110...120 V
N.O. N.C. 89 110...115 V 115...127 V
Main contacts 36 190 V 220 V
80 220...230 V 230...240 V
88 230...240 V 240...260 V
Contactor type 42 230...240 V 277 V
UA Capacitor switching - AC operated 85 380...400 V 400...415 V 1SBC101601S0201 - Rev. E
86 400...415 V 415...440 V
75 200 V 200...220 V
Codes in bold for dual frequency coils.
