       E1250DU electronic overload relays – 375 to 1250 A
       Ordering details





                                  Description
                                  The E1250DU are self-supplied electronic overload relays, which means no extra external supply is
                                  needed. It offers reliable protection for motors in the event of overload or phase failure. Easy to use like a
                                  thermal overload relay and compatible with standard motor applications, the electronic overload relay is
                                  convincing, above all, due to its wide setting range, high accuracy, high operational temperature range and
                                                    1SFC101025F0201  the possibility to select a trip class (10E, 20E, 30E). Further features are the temperature compensation,
                                  trip contact (N.C.), signal contact (N.O.), automatic or manual reset selectable, trip-free mechanism, STOP
                                  and TEST function and a trip indication. Busbar kits are available as accessory for contactor mounting.
                                  Ordering details
                                  Setting range  Short-circuit    Trip class  Type   Order code           Weight
       E1250DU-1250                             protective device                                         (1 pce)
                                  A                                                                       kg
                                  E1250DU electronic overload relay
                                  375 ... 1250  -            10E, 20E, 30E  E1250DU-1250  1SFA739001R1000  12.181
