         EF65, EF96, EF146 electronic overload relays – 20 to 150 A
         Ordering details





                                    Description
                                    The EF65, EF96 and EF146 are self-supplied electronic overload relays, which means no extra external
                                    supply is needed. It offers reliable protection for motors in the event of overload or phase failure. Easy to
                                    use like a thermal overload relay and compatible with standard motor applications, the electronic overload
                                2CDC231001F0012  relay is convincing, above all, due to its wide setting range, high accuracy, high operational temperature
                                    range and the possibility to select a trip class (10E, 20E, 30E). Further features are the temperature
                                    compensation, trip contact (N.C.), signal contact (N.O.), automatic or manual reset selectable, trip-free
                                    mechanism, STOP and TEST function and a trip indication. The overload relays are connected directly to
                                    the contactors. The EF65, EF96 and EF146 have ATEX certification  .
                                                                                     1)
         EF65-70
                                    Ordering details
                                    Setting range  Short-circuit    Trip class  Type   Order code           Weight
                                                  protective device                                         (1 pce)
                                    A             160 A, fuse type gG  10E, 20E, 30E  EF65-56  1SAX331001R1102  kg
                                                                                                            0.821
                                    20 ... 56
                             2CDC231002F0012  25 ... 70  160 A, fuse type gG  10E, 20E, 30E  EF65-70  1SAX331001R1101  0.821
                                                                                                            0.802
                                                               10E, 20E, 30E
                                                  200 A, fuse type gG
                                                                                       1SAX341001R1101
                                                                            EF96-100
                                    36 ... 100
                                                                                       1SAX351001R1101
                                                               10E, 20E, 30E
                                                                                                            0.879
                                                                            EF146-150
                                                  315 A, fuse type gG
                                    54 ... 150
         EF96-100                   1)  ATEX is valid for products, produced from week 42, 2014. ATEX certification is valid for EF65-56, produced from week 47, 2015.  6
                                    Ordering details accessories
                                    Suitable for        Description         Type       Order code           Weight
                                                                                                            (1 pce)
                                                                                                            kg
                                    EF96, TF96          Single mounting kit 2)  DB96   1SAZ901901R1001      0.190
                                                                            KPR-101L
                                                                                                            0.019
                                    EF65, EF96, EF146
                                                        Reset push button
                                                                                       1SFA616162R1014
                             2CDC231003F0012  2)  Note: for more information see catalog 1SFC151004C0201
         EF146-150
                                    Main dimensions mm, inches
                                              55  2.17"
                                             34.65  1.36"                              43.7  1.72" 8  0.31"  56.6  2.23"  3  0.12"
                                               8  0.31"     17.2  0.68"  3  0.12"                      17.2  0.68"
                                                            53.3  2.1"
                             2CDC231001V0015           1"  25.4   0.39"                          25.4  1"
                                    120.2  4.73"  105.2  4.14"  38.4 1.51"  10   121.7  4.79"  38.4  1.51"  10  0.39"
         DB96                         3.35"  85.2   2.92"  103.2  4.06"       105.2  4.14"  85.2  3.35"  4.06"  103.2
                                       74.2                                     74.2  2.92"
                                                        11  0.43"                                  11  0.43"
                                                          3  0.12"                                   3  0.12"
                                              16 0.63"  5.5 0.22"  74  2.91"  2CDC232001F0012  16  0.63"  5.5  0.22"  74  2.91"  2CDC232002F0012
                                              37  1.46"       101.4  3.99"             37  1.46"
                                              58  2.28"                                58  2.28"         101.4  3.99"
                                              70  2.76"        105.2 4.14"             70  2.76"          105.2  4.14"
                             2CDC231002V0015  EF65-56 / EF65-70 2.37" 6.6  0.26"  15.5   0.61"  4  0.16"  EF96-100
                                               89.05   3.51"
                                               60.1
                                                 13   0.5"
         DB96 + EF96

                                    139.4   5.49"  127   5"  119.25   4.69"  117.4   4.62"  88.9   3.5"  85.2   3.35"  38.4   1.51"  10  0.39"
                         1SFC151224F0002   74.2   2.92"   103.7   4.08"  11  0.43"



         KPR-101L                              16  0.63"  5.5  0.22"  3  0.12"  74   2.91"  2CDC232003F0012
                                               37   1.46"      101.4   3.99"                                        2CDC107038C0201a
                                               58   2.28"
                                               70   2.76"       105.2   4.14"
                                    EF146-150
