AF116B..RT ... AF370B..RT 3-pole contactors

Main accessories

Ordering details (1)
For contactors Auxiliary Type Order code Pkg Weight
contacts qty (1 pce)

1SFC101071V0001 kg

Side-mounted instantaneous auxiliary contact blocks
AF116B..RT ... AF370B..RT 1st block 1 1 CAL19B-11-RT 1SFN010829R1011 2 0.04 3
CAL19B-11-RT 2nd block 1 1 CAL19B-11B-RT 1SFN010829R3311 2 0.04

Mechanical interlock unit
AF116B..RT ... AF370B..RT VM19 1SFN030300R1000 1 0.054
AF116B..RT ... AF146B..RT and AF190B..RT, AF205B..RT VM140/190 1SFN034403R1000 1 0.088
AF190B..RT, AF205B..RT and AF265B..RT ... AF370B..RT VM205/265 1SFN035203R1000 1 0.09
Note: To mount VM mechanical interlock unit, remove CAL19B-11-RT.
Terminal shrouds LT140-30L 1SFN124203R1000 2 0.07
1SFC101035V0001 AF190B..RT, AF205B..RT, with cable clamps LT205-30C 1SFN124801R1000 2 2 0.05
AF116B..RT ... AF146B..RT, with compression lugs
AF190B..RT, AF205B..RT, with compression lugs
1SFN124803R1000
LT205-30L
0.22
and TOL/EOL in DOL-starters
VM19 AF190B..RT, AF205B..RT, with shorting bar or between contactor LT205-30Y 1SFN124804R1000 1 0.05
AF265B..RT ... AF370B..RT, with cable clamps LT370-30C 1SFN125401R1000 2 0.035
AF265B..RT ... AF370B..RT, with compression lugs LT370-30L 1SFN125403R1000 2 0.28
AF265B..RT ... AF370B..RT, with shorting bar or between contactor LT370-30Y 1SFN125404R1000 1 0.075
and TOL/EOL in DOL-starters 1SFN125406R1000 1 0.15
1SFC101041V0001 ATK300/2 and OZXB4
AF265B..RT ... AF370B..RT, for use with extending cable clamps, LT370-30D
For contactors Dimensions Type Order code Pkg Weight
LT370-30C
hole Ø bar qty (1 pce)
mm mm kg
Terminal enlargements
AF116B..RT ... AF146B..RT 6.5 13 x 3 LW140 1SFN074207R1000 1 0.115
AF190B..RT ... AF205B..RT 10.5 17.5 x 5 LW205 1SFN074807R1000 1 0.26
AF265B..RT ... AF370B..RT 10.5 20 x 5 LW370 1SFN075407R1000 1 0.34
1SFC101049V0001 Terminal extension 6.5 13 x 3 LX140 1SFN074210R1000 1 0.072
AF116B..RT ... AF146B..RT
AF190B..RT ... AF205B..RT
0.234
1SFN075410R1000
10.5
20 x 5
LX370
AF265B..RT ... AF370B..RT 8.5 17.5 x 5 LX205 1SFN074810R1000 1 1 0.18
LX140 (1) For more information, refer to "Accessories" section.

1SFC101258C0201 - Rev. A

ABB | 3/19
