Main accessories
MS132-B, MS165-B, MO132-B, MO165-B

Ordering details
Suitable for Rated control supply voltage Type Order code Pkg Weight
qty (1 pc)
50 Hz 60 Hz
V AC V AC pcs kg
2
Shunt trips – mountable on the left
MS132-B, MS165-B, 20 ... 24 20 ... 24 AA1-24 1SAM201910R1001 1 0.100
1SBC101211F0014 110 110 AA1-110 1SAM201910R1002 1 1 1 0.100
MO132-B, MO165-B
1SAM201910R1003
AA1-230
200 ... 240
200 ... 240
0.100
0.100
350 ... 415
350 ... 415
AA1-400
1SAM201910R1004
AA1-24 Undervoltage releases – mountable on the left
MS132-B, MS165-B, 20 24 UA1-20 1SAM201904R1010 1 0.100
MO132-B, MO165-B 24 - UA1-24 1SAM201904R1001 1 0.100
48 - UA1-48 1SAM201904R1002 1 0.100
60 - UA1-60 1SAM201904R1003 1 0.100
110 120 UA1-110 1SAM201904R1004 1 0.100
- 208 UA1-208 1SAM201904R1008 1 0.100
230 240 UA1-230 1SAM201904R1005 1 1 0.100
1SBC101212F0014 415 480 UA1-415 1SAM201904R1007 1 1 0.100
UA1-400
1SAM201904R1006
0.100
400
-
-
1SAM201904R1009
0.100
575
UA1-575
UA1-24 Screw fixing kit
MS132-B, MO132-B - - FS116 1SAM201909R1001 10 0.020
Ø 4.5 Ø 0.18" 9 0.35" 5.4 0.21" Ø 0.18" 0.35" 0.21"

4.8" 4.33" 4.8" 4.33"
122 110

2CDC242017F0009 2CDC242018F0009

17.5 0.69" 0.69"
MS132 + FS116 ≤ 10 A MS132 + FS116 > 10 A

2CDC131100C0201
