AF116B ... AF370B 3-pole contactors

Main accessories

Ordering details (1)
For contactors Auxiliary Type Order code Pkg Weight
contacts qty (1 pce)
kg
1SFC101071V0001 2

AF116B ... AF370B
CAL19-11
1
1
1st block
CAL19-11 Side-mounted instantaneous auxiliary contact blocks 1SFN010820R1011 2 0.04
2nd block 1 1 CAL19-11B 1SFN010820R3311 2 0.04
Mechanical interlock unit
AF116B ... AF370B VM19 1SFN030300R1000 1 0.054
AF116B ... AF146B and AF190B, AF205B VM140/190 1SFN034403R1000 1 0.088
AF190B, AF205B and AF265B ... AF370B VM205/265 1SFN035203R1000 1 0.09
Note: to mount VM mechanical interlock unit, remove CAL19-11.
Terminal shrouds
1SFC101035V0001 AF116B ... AF146B, with compression lugs LT140-30L 1SFN124203R1000 2 2 0.07
1SFN124801R1000
0.05
AF190B, AF205B, with cable clamps
LT205-30C
AF190B, AF205B, with compression lugs
1SFN124804R1000
LT205-30Y
AF190B, AF205B, with shorting bar or between contactor LT205-30L 1SFN124803R1000 2 1 0.22
0.05
VM19 and TOL/EOL in DOL-starters
AF265B ... AF370B, with cable clamps LT370-30C 1SFN125401R1000 2 0.035
AF265B ... AF370B, with compression lugs LT370-30L 1SFN125403R1000 2 0.28
AF265B ... AF370B, with shorting bar or between contactor LT370-30Y 1SFN125404R1000 1 0.075
and TOL/EOL in DOL-starters
1SFC101041V0001 AF265B ... AF370B, for use with extending cable clamps, LT370-30D 1SFN125406R1000 1 0.15
ATK300/2 and OZXB4
For contactors Dimensions Type Order code Pkg Weight
LT370-30C
hole Ø bar qty (1 pce)
mm mm kg
Terminal enlargements
AF116B ... AF146B 6.5 13 x 3 LW140 1SFN074207R1000 1 0.115
AF190B ... AF205B 10.5 17.5 x 5 LW205 1SFN074807R1000 1 0.26
AF265B ... AF370B 10.5 20 x 5 LW370 1SFN075407R1000 1 0.34
1SFC101049V0001 Terminal extension 6.5 13 x 3 LX140 1SFN074210R1000 1 0.072
AF116B ... AF146B
AF190B ... AF205B
1SFN075410R1000
10.5
0.234
LX370
20 x 5
AF265B ... AF370B 8.5 17.5 x 5 LX205 1SFN074810R1000 1 1 0.18
LX140
(1) For more information, refer to "Accessories" section.

1SFC101275C0201

ABB | 2/65
