NF 8-pole contactor relays
Contactor relays and main accessories
03
NF contactor relay
CAL4-11
2-pole auxiliary
contact block BX4-CA
Protective cover
Main accessory fitting details - for ordering details, technical data and other accessories: see section accessories
Contactor relay Main Side-mounted accessories
types poles Auxiliary contact blocks
2-pole CAL4-11 (1)
Left side Right side
NF 4 4 E 1 –
5 3 E
6 2 E
7 1 E
8 0 E
3 3 / 1 1
5 1 / 1 1
(1) not allowed for 24 V DC operated contactor relay (coil 30).
