ABB MOTOR PROTECTION AND CONTROL 3/315

—

Function markers
Mounting piece

BA5-50 Function markers 03
Set of 50 function markers designed to be clipped onto the front face of devices. Details can be
added to these markers using a ball point pen, indelible felt-tip pen or pentel white.
Self-adhesive labels (not supplied) can also be added to them.
Marker dimensions: 7 x 19 mm (0.276" x 0.748").

1SBC575874F0301 For contactors Type Order code Pkg Weight
qty
(1 pce)
kg
GA75, GAE75
BA5-50 UA, UA..RA and accessories BA5-50 1SBN110000R1000 1 0.017

BP16 Mounting piece
Mounting piece for screw fixing (M4, not supplied) of UA, UA..RA series contactors indicated in
the table below.
1SBC586724F0302 Easy handling of screwdrivers and screw driving.
Add-on mounting piece on contactor's rear face, offering a wide fixing facility.
For contactors Type Order code Pkg Weight
qty (1 pce)
kg
UA16, UA16..RA BP16 1SBN111403R1000 100 0.141

BP16

35 1.38" ø 4.5 0.18"
M4 8-32 UNC

84 3.31"

1SBC101531S0201 - Rev. B
4.5 0.18" 4.5 0.18"
Drilling plan for UA16, UA16..RA contac-
tors with BP16
