5/90 ABB MOTOR PROTECTION AND CONTROL

—

Connecting links for starting solutions and other accessories

Connecting links
The BEA16-3U insulated connecting links are used to connect an AS..S AC operated contactor or
an ASL..S DC operated contactor with a manual motor starter.
The connecting link ensure the electrical and mechanical connection between the contactor and
the manual motor starter.
1SBC101384F0010 kg
BEA16-3U For contactors Manual motor Type Order code Pkg Weight
qty
(1 pce)
starter
AS09..S ... AS16..S
ASL09..S ... ASL16..S MS116-0.16 ... MS116-16 BEA16-3U 1SBN081020R1000 1 0.045
MS132-0.16 ... MS132-16
05
Test block
BDT4 test block is suitable for switching on contactor off-load.
1SBC100043V0014 For contactors Type Order code Pkg Weight
Marking on the block indicates the contactor type to fit with.
(1 pce)
qty
kg
BDT4
AS..S, ASL..S, NS..S, NSL..S BDT4 1SBN110122T1000 10 0.007

Function markers
1SNC160101F0014 Box of 16 blank cards (16 markers by card) printable on HTP500 thermal transfer printer and AMS
500 marking table to identify your contactors, overload relays or manual motor starters.
Marker dimensions: 7 x 20 mm (.276" x .787").
For contactors Type Order code Pkg Weight
qty (1 pce)
BA4
kg
AS..S, ASL..S, NS..S, NSL..S BA4 1SNA235156R2700 16 0.011
AMS 500 support plate for 8 BA4 SPRC 1 1SNA360010R1500 1 0.220
HTP500 support plate HTP500-BA4 1SNA235712R2400 1 0.290
