Compact range
Illuminated extended pushbuttons - Maintained

Operator Bezel Contacts Type Order code Pkg Weight
qty
(1 pce)
1SFC151210V0001 kg
Rated voltage 24 V AC / DC
CP4-11R-10
l Red Black plastic 1 0 CP4-11R-10 1SFA619103R1111 10 0.025
1SFC151213V0001 l Green Black plastic 1 0 CP4-11G-10 1SFA619103R1112 10 0.025
1SFA619103R1141
10
0 1
CP4-11R-01
0.025
03
l Yellow
CP4-11Y-10
Black plastic
0.025
10
1SFA619103R1113
1 0
l Blue Black plastic 1 0 CP4-11L-10 1SFA619103R1114 10 0.025
CP4-11G-10 Rated voltage 110…130 V AC / DC CP4-11C-10 1SFA619103R1118 10 0.025
1 0
Black plastic
Clear
1SFC151208V0001 l Red Black plastic 1 0 CP4-12R-10 1SFA619103R1211 10 0.025
CP4-12R-01
1SFA619103R1241
10
0 1
0.025
1SFA619103R1213
CP4-12Y-10
l Yellow
CP4-11Y-10 l Green Black plastic 1 0 CP4-12G-10 1SFA619103R1212 10 0.025
10
0.025
1 0
Black plastic
l Blue Black plastic 1 0 CP4-12L-10 1SFA619103R1214 10 0.025
Clear Black plastic 1 0 CP4-12C-10 1SFA619103R1218 10 0.025
Rated voltage 220 V AC / DC
l Red Black plastic 1 0 CP4-13R-10 1SFA619103R1311 10 0.025
0 1 CP4-13R-01 1SFA619103R1341 10 0.025
l Green Black plastic 1 0 CP4-13G-10 1SFA619103R1312 10 0.025
l Yellow Black plastic 1 0 CP4-13Y-10 1SFA619103R1313 10 0.025
l Blue Black plastic 1 0 CP4-13L-10 1SFA619103R1314 10 0.025
Clear Black plastic 1 0 CP4-13C-10 1SFA619103R1318 10 0.025

1.5 0.06" - 6 0.24"

Ø 30 1.18" Ø 20 0.79" Ø 29 1.14"

42 1.65" 17.5 0.69"
CP4 1SFC151042S0201
Dimensions (mm, inches)
