92 ABB PILOT DEVICES – THE COMPLETE OFFERING

—

Enclosures
Metal enclosures and accessories

—
Description
When ordering complete enclosure:
1SFC151309F0001 • Select operators
• Select contact blocks and LED blocks for front mounting and holder

• For 4- and 6-seat enclosure select blanking plate.
KEM • Select cable gland (holes for cable glands Pg 16)
Description Color Type Order code Pkg Weight
qty (1pce)
1SFC151488F0001 Empty cast aluminum enclosures for front mounted pilot devices. kg

SK1707685 Degree of protection IP66, IP67 and IP69K. KEM1-0 SK616701-AA 1 0.40
1SFC151489F0001 2-seat Light grey KEM2-0 SK616702-AA 1 1 0.70
Light grey
1-seat
0.80
3-seat
KEM3-0
SK616703-AA
Light grey
04
SK1750152 4-seat Light grey KEM4-0 SK616704-AA 1 1 1.20
1.40
SK616706-AA
KEM6-0
Light grey
6-seat
1SFC151490F0001 —
Accessories
qty (1pce)
SK172105-AE Pr Pg Diameter Order code Pkg Weight
mm kg
Cable gland
1SFC151394V0001 Metal, threaded outer sleeve 16 8.5 ... 11.5 SK1707685 1 0.040
22.5
22.5
SK1707687
16
12.5 ... 15.0
22.5 16 10.5 ... 13.5 SK1707686 1 1 0.045
0.050
MA1-8129 Metal hexagon nut
1SFC151395V0001 For use with cable glands above 16 SK1750152 1 0.010
22.5
Blanking plates without holes
MA1-8130 Metal, black, for 4- and 6-seat metal enclosures
1SFC151393V0001 For flange opening Suitable flange gasket SK172105-AA 1 0.010
SK1704536
FL 13
Note: Flange gasket not included
MA1-8136
Blanking plates with holes
Metal, black, for 4- and 6-seat metal enclosures
For flange opening Suitable flange gasket
Two holes Pr 22.5 (Pg 16) SK172105-AD 1 0.110
Hole centre distance 50 mm
FL 13 SK1704536
Three holes Pr 22.5 (Pg 16) SK172105-AE 1 0.110
Hole centre distance 38 mm
FL 13 SK1704536
Note: Flange gasket not included
Flange gasket
FL 13 SK1704536 1 0.005
Blanking plug
For 22 mm-hole
Grey MA1-8129 1SFA611920R8129 10 0.005
Black MA1-8130 1SFA611920R8130 10 0.005
Light grey MA1-8136 1SFA611920R8136 10 0.005
Note: Applicable to cover a 22 mm-hole in an enclosure instead of an operator. Gasket and nut included.
Sealing plug
Grey plastic
Pr Pg
22.5 16 SK175919-3 10 0.010 1SFC151062S0201
Note: Use when cable gland us not needed.
