Page 215 - 1SNK160027C0207_SNK Series Terminal Blocks
P. 215
End sections
Pluggable terminal block accessories
EDK2.5-22 end sections
1SNK160301V0014 Description
– Compatible with ZDK2.5-22 and ZDK4-22 pluggable terminal blocks.
Ordering details
Description Color Type Order code Pkg Weight
EDK2.5-22 qty (1 pce) g
2.2 mm 0.087 in spacing Dark grey EDK2.5-22 1SNK805910R0000 20 3.15
EDS4-22 end sections 5
Description
1SNK160302V0014 Ordering details
– Compatible with ZDS4-22 pluggable terminal block.
Description Color Type Order code Pkg Weight
qty (1 pce) g
EDS4-22 0.8 mm 0.031 in spacing Dark grey EDS4-22 1SNK805911R0000 20 1.85
Main technical data
Material specifications Insulating material Polyamide
Flammability V0
NF F 16 101 I2F2
Ambient temperature Service IEC 60068-2-1 -55 ... +110 °C -67 ... +230 °F
min/max Storage -55 ... +110 °C -67 ... +230 °F
Installing -5 ... +40 °C +23 ... +104 °F
All the main technical data provided are "manufacturer" values. 1SNK164010S0201
RoHS
All the technical data for UL/CSA standard and dimensions in inches are in italic.
Technical data valid for copper conductors only.
ABB SNK series - Terminal blocks | 211
