Page 220 - 1SNK160027C0207_SNK Series Terminal Blocks

Marking systems

Selection guide

For high volume For versatile applications For basic marking applications
terminal blocks applications

Marking systems HTP500-V2 MG3 AMS 600 AMS 250
6
Technology Thermal transfer Thermal transfer Plotter
Printing mode Manual / Auto (up to 64 cards) Manual Manual
Printing speed High Medium Low
Printing quality 300 x 600 dpi 300 x 600 dpi 300 x 300 dpi

1 ribbon or ink cartridge printing capacity ~ 60 000, RC510 markers (5 x 10 mm markers) ~ 160 000, MG-CPM (5 x 10 mm markers) ~ 230 000 markers (with 3 characters per markers)
Printing color available (monochrome) Black / Red Black / Red / Blue / Green / White Black
Terminal block markers material Polycarbonate Polycarbonate Polyamide
Terminal block markers
SNK series terminal blocks blank markers polyamide – – MC…PA

SNK series terminal blocks blank markers polycarbonate MC MG-CPM –
SNK series terminal blocks blank markers PVC – MG-CPMF –
End stop markers 2 marker types 2 marker types 4 marker types
Other terminal blocks manufacturers blank markers 3 manufacturers 15 manufacturers 5 manufacturers

Wires and cables markers 2 marker types 4 marker types 1 marker type
Components and equipment markers 4 marker types 9 marker types 9 marker types

216 | ABB SNK series - Terminal blocks
