APPLIC ATION DESCRIPTIONS AND ADDITIONAL INFORMATION 227

Integral solution AC500 can interface to a large amount of IEDs
All-in-one platform 60870-104, 61850, Modbus, and map their data in control and monitoring di-
combined with OPC DA, OPC UA, MQTT. rection to a 60870-5-104 , OPC UA or MQTT com-
Automation Builder Engineering with the com- munication as required or act on other IEDS e.g
fortable IED configuration tool and flexible IEC with advanced logic in load shedding control ap-
programming functionality and C-code integra- plications. AC500 can also help to modernize and
tion. digitalize an existing and aging infrastructure.

Application example 61850
AC500 can precisely control and monitor all levels
(switchboard, substation and process) and con- Please watch our videos on our
nect them via 61850 or interface to the outside ABB PLC YouTube channel:
world (RTU).

www.youtube.com/user/abbplc

AC500

application levels

Control Center AC500
Cloud-based local or remote PLC
services

Management and control

Station/substation

Station bus
08

Bay

Process bus

Process
