ABB softstarters

A solution for every need

ABB’s softstarter offering consists of three ranges, covering every need. The 1 1
products help you secure motor reliability, improve installation efficiency and
increase application productivity.

PSR – The compact range PSE – The efficient range PSTX – The advanced range

Technical data: Technical data: Technical data:
Rated motor current 3...105 A Rated motor current 30...370 A Rated motor current 30...1250 A
(inside delta: 2160 A)
Main motor voltage 208...600 V Main motor voltage 208...600 V
Main motor voltage 208...690 V
Control supply voltage 100...240 V AC or 24 Control supply voltage 100...250 V AC
V AC/DC Control supply voltage 100...250 V AC

Softstarter feature selection guide

Current limit ramp and dual current limit Power factor underload protection Customer defined protection Overvoltage/undervoltage protection Graphical display and keypad Programmable warning functions Jog with slow speed forward/ reverse
PTC/PT100 input for motor protection
Current/Voltage imbalance protection
Electronic motor overload protection
Inside-delta connection possible
Motor runtime and start count
Overload time-to-cool
Underload protection
Electricity metering
Built-in bypass
Motor heating
Current limit Dual overload protection Locked rotor protection Phase reversal protection Earth-fault protection Detachable keypad Diagnostics Overload time-to-trip Analog output Fieldbus communication Multiple languages Torque control Torque limit Coated PCBA Limp mode Dynamic brake Stand still brake Sequence start Full voltage start Manual pump cleaning
Event log
Kick start
PSR – – – – – – – – – – – – – – • – – – – – – – – – o – – – – – – – – – – – – – –
PSE • – • – • – • – – – – – – – • – • – – – – – – • o o – – • – • – – – – – – • –

PSTX • • • • • • • • • • • • • • • • • • • • • • • • • • 17 • • • • • • • • • • • •
Secure motor reliability Improve installation efficiency Increase application productivity

• Standard o Opional – Not available
