ENTRELEC terminal blocks offering

TE Connectivity proposes one of the largest connection offering on the market with
various technologies: screw, PI-Spring, spring, IDC, pluggable, stud, etc. Technologies

found in over 8000 products & solutions.

SNK & SNA standard Specific technologies Terminal blocks for

1 terminal blocks railway applications

Scope Qualified for worldwide applications and Specific terminal blocks and technologies The largest offering on
severe environments (such as hazardous for dedicated applications and markets. the market for rolling
locations, railways, marine and solar stock and infrastructures.
applications..).
From 0.2 to 300 mm².
®
Product SNK PI-Spring Feed-through ADO System (IDC) ADO-ADO or ADO-screw clamp SNK PI-Spring technology
families & technology Multi-deck 0.22 to 4 mm² Feed-through / Multi-deck / 2.5 to 16 mm²
functions 2.5 to 16 mm² Ground 24 to 12 AWG Ground / Disconnect / 12 to 4 AWG
12 to 4 AWG Disconnect for fuses / Component holder
for fuses
Component holder
Safety (spring loaded) Feed-through SNK pluggable
0.22 to 10 mm² Disconnect screw & PI-Spring technologies
24 to 6 AWG Test & measurement 2.5 to 4 mm²
12 to 10 AWG
®
SNK screw clamp Feed-through Stud One stud ADO System (IDC)
technology Multi-deck 25 to 120 mm² 2 studs 1.5 to 4 mm²
4 to 240 mm² Ground 2 AWG to 500 Kcmil One stud - One wire-clamp 16 to 12 AWG
12 to 500 Kcmil Disconnect
for fuses Ring lug Feed-through Stud
Test & measurement 2.5 to 25 mm² Test & measurement 4 to 185 mm²
Marshalling 14 to 4 AWG
Component holder
SNK pluggable Feed-through Miniblocks Screw clamp Quick-connect
screw & PI-Spring Multi-deck 1.5 to 6 mm² Spring 2.5 to 6 mm²
technologies Ground 18 to 8 AWG ADO System (IDC)
®
2.5 to 4 mm²
12 to 10 AWG
SNA Stud Feed-through Other types
35 to 300 mm² Stud-stud Test & measurement: with sliding link, blade, plug
1 AWG to 1000 Kcmil Hybrid Pluggable: feed-through, double deck, disconnect
Stud-screw Sensors/actuators: screw, spring, ADO system (IDC)
Installation: screw, spring
Protection: ground + neutral
Component holders: screw, spring, ADO system (IDC)

www.te.com

INDUSTRIAL /// ENTRELEC - SNK TERMINAL BLOCKS
