Guarantee access
only to authorized operators
cover can be permanently sealed with a seal or cable tie.
Centering drilling guide for seal or cable tie.
The cover is specially designed to ease its mounting or removal:
– Hook shape on each side for convenient removal with screwdriver

Assembly with protecting cover Drilling and centering guide

3

Seal with cable tie Convenient removal with screwdriver

CT side PT side

sliding link status: closed

Disconnect sliding link status:
Open and close symbols help to
visualize the sliding link position

sliding link status: opened

Measuring equipment side

Short-circuit CT circuits safely and
conveniently

1 Fully operated by screwdriver (DIA 3.5 mm)
2 Short-circuited position secured thanks to AJS9 test sockets tightening
3 Adapted hook shape maintain the bridge on terminal block in the 1SNK160057S0201
non connected position
