Other accessories

1SBC100020V0014 Ordering details Type Order code Pkg Weight

For contactors
(1 pce)
qty
kg
LDC4
Additional coil terminal blocks
1SBC100021V0014 Additional coil terminal blocks for a bottom access to the coil terminals of contactors or contactor relays.

1SBN070156T1000
0.010
AF09 ... AF96, NF
10
LDC4
BX4 Protective covers
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against
accidental contact.
1SBC100023V0014 AF09 ... AF96 1-stack contactors and NF contactor relays BX4 1SBN110108T1000 10 0.006
5 4-pole CA4, 2-pole CAT4 auxiliary contact blocks and BX4-CA 1SBN110109W1000 50 0.001
BX4-CA TEF4 electronic timer
Note: BX4 produced since 13045 (day 045 - year 2013) are suitable for AF40 ... AF96.

Function markers AF09 ... AF370
1SNC160101F0014 Box of 16 blank cards (16 markers by card) printable on HTP500 thermal transfer printer and AMS 500
marking table to identify your contactors, overload relays or manual motor starters.
Marker dimensions: 7 x 20 mm (.276" x .787").
AF09 ... AF370 contactors, TF thermal overload relays, EF elec- BA4 1SNA235156R2700 16 0.011
BA4 tronic overload relays and MS116, MS132 manual motor starters
AMS 500 support plate for 8 BA4 SPRC 1 1SNA360010R1500 1 0.220
HTP500 support plate HTP500-BA4 1SNA235712R2400 1 0.290

1SBC100044V0014 Function markers AF400 ... AF2650
Set of 50 function markers designed to be clipped onto the front face of devices. Details can be added to
these markers using a ball point pen, indelible felt-tip pen or pentel white.
Self-adhesive labels (not supplied) can also be added to them.
BA5-50 Marker dimensions: 7 x 19 mm (.276" x .748").
AF400 ... AF2650 and accessories BA5-50 1SBN110000R1000 1 0.017

Main dimensions mm, inches

44.8 1.76"
6
0.24"

28 1.10"
1SBC101733S0201

BX4

5/366 | ABB
