Voltage code table

The below tables indicate the available coil voltages and corresponding digits for order codes.

3-pole contactors - with spring terminals

Auxiliary contacts
N.O. N.C.
Type Order code
AF09 - 30 - 10 S - 12 1SBL137004R 12 10
AC coil code DC coil code
50/60 Hz
N.O. N.C. 11 24...60 V 20...60 V
Main contacts 12 48...130 V 48...130 V
13 100...250 V 100...250 V
Contactor with spring terminal 14 250...500 V 250...500 V
Contactor type
AF.. AC / DC operated

6 3-pole contactors - low consumption - with spring terminals

Low coil consumption
Auxiliary contacts
N.O. N.C.
Type Order code
AF09 Z - 30 - 10 S - 21 1SBL136004R 21 10
AC coil code DC coil code
50/60 Hz
N.O. N.C. 20 – 12...20 V
Main contacts 21 24...60 V 20...60 V
22 48...130 V 48...130 V
Contactor with spring terminal
Contactor type 23 100...250 V 100...250 V
AF.. AC / DC operated

Contactor relays - with spring terminals

Contactor with spring terminal
Type Order code
NF 22 E S - 12 1SBH137004R 12 22
AC coil code DC coil code
N.O. N.C. 50/60 Hz
Number contacts 11 24...60 V 20...60 V
12 48...130 V 48...130 V
13 100...250 V 100...250 V
Contactor type 14 250...500 V 250...500 V
NF AC / DC operated

Contactor relays - low consumption - with spring terminals

Low coil consumption
Contactor with spring terminal
Type Order code
NF Z 22 E S - 21 1SBH136004R 21 22

AC coil code DC coil code
N.O. N.C. 50/60 Hz
Number contacts 20 – 12...20 V
21 24...60 V 20...60 V 1SBC101729S0201
Contactor type 22 48...130 V 48...130 V
NF AC / DC operated 23 100...250 V 100...250 V
