P. 775
R contactors
Get the right product
Conventional applications
AC circuit switching DC circuit switching
Up to 500 V AC From 500 up to 1000 V AC Up to 1500 V DC with poles in series
IOR contactors IOR..MT contactors IOR..CC contactors
AC-1 Rated operational current up to 5000 A DC-1 Rated operational current up to 5000 A
AC-3 Rated power up to 1500 kW (1520 A - 440 V) DC-3 / DC-5 operational current up to 2000 A
Advanced applications
N.O./N.C. main poles combination Power circuit coupling Slip-ring motor control
AC circuit switching DC circuit switching Up to 1000 V AC / 1500 V DC Uer up to 5000 V AC 9
NOR..MT contactors NOR..CC contactors LOR couplers FOR contactors
Energy saving and safety requirements Alternator field discharge
Equipped with latching Umax 2250 V DC
..AMA, ..AME contactor types AM-CC-JORE contactors
1SBC104006S0201
ABB | 9/3
