DOL starters protected by thermal overload relays

With AF..B contactors - open type version in kit form

Main dimensions mm, inches
77 3.03" 86 3.39" 86 3.39"
10
10
45 1.77" 71 2.80" 10 35 1.38" 2 x 45 1.77" 45 1.77" 80 3.15" 80 3.15" 35 1.38" 2 x 35 1.38" 2 x
0.39"
0.39" 5.5 0.22" 5.5 0.22" 0.39" ø 4.2 0.17" M4 8-32 UNC M4 8-32 UNC
ø 4.2 0.17"
5.5 0.22" ø 4.2 0.17" M4 8-32 UNC
2
35 mm EN/IEC 60715 5.5 0.22" 60 2.36" 70 2.76" 35 mm EN/IEC 60715 5.5 0.22" 35 mm EN/IEC 60715 5.5 0.22" 60 2.36" 60 2.36" 70 2.76" 70 2.76"
156.1 6.15" 5 0.20" 158.9 6.26" 158.9 6.26" 5 0.20" 5 0.20"
5 0.20" 5 0.20" 5 0.20"
6.2 9.2 9.2
0.24" 0.36" 0.36"

72.7 2.86" 75.7 2.98" 75.7 2.98"
76.8 3.02" 79.8 3.14" 79.8 3.14"
AF09(Z)B, AF12(Z)B, AF16(Z)B AF26(Z)B, AF30(Z)B, AF38(Z)B
+ TF42-B thermal overload relay + TF42-B thermal overload relay
Note: contactor lateral distance to grounded component 2 mm 0.08" min.
