Easier than ever wiring

03

Intuitive wiring
With Push-in Spring, all cables and connecting links use the
same round shape entry, whilst the square terminals above
are clearly marked with screwdriver symbols. The result?
Wiring and de-wiring that’s intuitive and easily repeatable
without cabling error, with little to no training required.

Just one screwdriver required
For de-wiring, only one screwdriver size is needed for the
entire range. No twisting or turning is required either, so
there's less chance of damage to the terminals
and to your installation as a whole.

Automated wiring
The Push-in Spring motor starting solution features 90°
cable insertion for all terminals. Front access to terminals
aids smooth, robust insertion of cables and makes
automated robot wiring possible.
