Auxiliary contact blocks for AF116 ... AF2850 contactors

The auxiliary contact blocks are used for the operation of auxiliary circuits and control circuits for
standard industrial environments.
03
Types of auxiliary contact blocks for side mounting:
• CAL 2-pole block, with instantaneous N.O. + N.C. contacts.
1SFC101071V0001 For clipping onto the right- and/or left-hand side of the contactors.
The CAL ...-11B is a second block for mounting in addition to a first CAL ...-11 block, right- and/or
The auxiliary contact blocks are equipped with screw type connecting terminals delivered open,
CAL19-11 left-hand of the AF116 ... AF2850 contactors.
protected against accidental direct contact and bear the corresponding function marking.
For contactors Auxiliary Type Order code Pkg Weight
contacts qty (1 pce)

kg
Side-mounted instantaneous auxiliary contact blocks
AF116 ... AF370 1 1 CAL19-11 1SFN010820R1011 1 1 0.040
1SFC101082V0001 AF400 ... AF2850 1 1 CAL18-11 1SFN010720R1011 2 2 0.050
1SFN010820R3311
CAL19-11B
0.040
1 1
0.050
1SFN010720R3311
1 1
CAL18-11B
For each contactor type, refer to "Accessory fitting details" table.
CAL18-11
