Connection accessories for starting solutions- with Push-in Spring terminals

For contactors Auxiliary Type Order code Pkg Weight 03
contacts qty (1 pce)
1SBC100083V0014 Mechanical and electrical interlock set (1) kg

AF26..K ... AF38..K
VEM4K AF09..K ... AF16..K 0 2 VEM4K 1SBN030113R1000 1 0.030
Note: - VEM4K includes a VM4 mechanical interlock unit with 2 fixing clips (BB4), a VE4K electrical interlock block
01NC 01NC
with A2 - A2 connection.
- VE4K block must be used with A2-A2 connection to respect the electrical connection diagram.
- VEM4K not suitable for AF..Z contactors with DC control voltage 12 ... 20 V DC (coil 20 and 24 V DC (coil 30).
KM1 KM2 For product availability, please consult your ABB local sales organization.
A2 A2
1SBC101673V0014 Connecting links with manual motor starters (1) 10 0.052
BEA16-4K1 1SBN081324T1000
with MS132-0.16K… MS132-25K
AF09..K ... AF16..K
0.057
10
BEA38-4K1 1SBN082324T1000
AF26..K ... AF38..K
with MS132-0.16K… MS132-32K
(1) For product availability, please consult your ABB local sales organization.
BEA16-4K1
Note: BEA not suitable for AF..Z contactors with DC control voltage 24 V DC (coil 30).

1SBC100452S0201
