B mini contactors

Smart - flexibility and diversity in a small size

04

AC
or

DC

Screw Flat pins Soldering pins
Screw terminals Flat pin terminals Soldering pin terminals
This conventional terminal type Thanks to really quick plug-in assembling, This connection type allows an easy
enables a quick connection to good reliability of the connection and low installation on PCB boards, where
an installation using just a one costs, the flat pin terminals are already all components have to be soldered
size screwdriver. All terminal the favorite choice in many industry in place.
screws, from power to control, sectors. The best option when high con- The soldering pins sustain currents
are aligned and accessible from nection speed is required. up to AC-1/AC-3 12 A.
the front for easy tightening.

Mountable in just about any place Save assembly time Perfect fit
According to the available space, auxil- This range offers reversing starters B mini contactors match manual motor
iary contacts can be mounted on the delivered as one piece from the factory. starters or overload relays. This
front or at the side of the B mini. Also, It avoids mounting mistakes and creates a space-saving and easy to
additional surge protection can be fit- secures operation. It is also available install motor starting solution for a
ted on any side of the contactor. with mechanical interlock for special complete protection and control of 2CDC102073C0201 - Rev. A
demands. your devices.
