ABB MOTOR PROTECTION AND CONTROL 12/75

—

Star-delta starters protected by electronic overload relays
With AF contactors - Open type version in kit form

270 10.63" 126 4.96"

281.5 11.08"

AF116, AF140, AF146
+ BEY140-4, VM19
+ EF146 electronic overload relay

14 x
30 1.18" 60 2.36" 30 1.18" 60 2.36" 30 1.18" M4 8-32 UNC

100 3.94"

43.8 1.72"

21.5
0.85" 12
94.7 3.73"

2 x
37 1.46" M5 10-24 UNC

1SFC101172C0201

Main dimensions mm, inches
