Page 173 - 1SBC104119C0202_MainCatalog_R contactors

AM-CC-JORE..21 and
AM-CC-JORE..31 types
R2500 … R4500

Contactor Number Fixing dimension - F Fixing
types holes
of poles acc. to number of CA15 auxiliary contacts:
R2500 ø
R3200 568 10 12 16 20
R3800 985 985 985 985
R4500 21 885 885 885 1250 1250 1250 1250
31 1150 1150 1150 985 985 985 985
21 885 885 885 1250 1250 1250 1250
31 1150 1150 1150 1050 1050 1050 1050
21 950 950 950 1300 1300 1300 1300
31 1200 1200 1200 1200 1200 1200 1200
21 1100 1100 1100

Contactor Number Dimensions
types of poles

A A1 B B1 D D2 D3 H I I1 M N Y

R2500 21 60 135 - 145 325 86 87 133 108 238 258 152 425
R3200 31 60 135 220 145 340 101 102 133 108 238 300 215 425
R3800 21 60 135 - 145 325 99 87 174 108 279 300 215 450
R4500 31 60 135 220 145 340 114 102 174 108 279 300 215 450
21 60 145 - 165 325 99 87 174 108 279 300 215 450
31 60 145 250 170 340 114 102 174 108 279 300 215 450
21 60 195 - 200 340 114 102 174 108 279 300 215 450

Fixing - Dimensions - Clearing distances - Connecting

9

220 280
35 50 50 50 35 40 40 40 40 40 40 40

45 20
45 20
1SBC104098S0201
8 x ø13 12 x ø13

R3800 (N.O.) R4500 (N.O.) ABB R contactors | 9/37

Terminal plate thickness for R2500 ... R5100: top and bottom terminal plates = 10 mm
