P. 168
AM-CC-JORE..21 and
AM-CC-JORE..31 types
R800 … R2100
Main dimensions mm
F 60 D
CA15
N.O. pole D2
N.C. pole 75
M 50 180 210
175 I1
I
N.C. N.O. N.O. N.O.
N 200 CA15 100 200
132 40 H
ø
A B1 B B N.O. pole D3
N.C. pole 77
Y
F 50
Fig 1 = right electro-magnet (see table in the following page) 60
F CA15
9 180
50
M
175
N.C. N.O. N.O. N.O.
N 200 CA15 ø
132 40 B A1
A B1 80
20 40 20
F
Fig 2 = central electro-magnet (see table in the following page)
Terminal plate details
48 11.5 48 60 17.5 100 25
11.5 25 11.5 25 11.5 17.5 25 25 50
12.5
25
12.5
25
12.5
25
30 15
30 15
4 x ø11 4 x ø11 1SBC104097S0201
2 x ø13 2 x ø13 2 x ø13 R1700 (N.O.)
R800 (N.O. / N.C.) R1000 (N.O.) R1400 (N.O.) R2100 (N.O.)
R1000 ... R2100 (N.C.)
Terminal plate thickness: top terminal plates = 10 mm, bottom terminal plates = 12 mm
9/32 | ABB R contactors
